Product Details
| Technical data | DT10 |
| Engine manufacturer | Briggs&Stratton |
| Type of motor | XR2100 |
| Cylinders | 1 |
| Displacement cc | 420 |
| Emission standards | Euro stage v&EPATier4 Final |
| Max engine output kW(@3600rpm) | 10 |
| Max engine torque Nm(@3060rpm) | 28.5 |
| Operating voltage V | 12 |
| Battery Ah | 45 |
| Shipping weight kg | 500 |
| Payload max kg | 1000 |
| Travel speed km/h | 0~4.2 |
| Max.grade ability | 30% |
| Fuel tank capacity l | 5.6 |
| Hydraulic oil tank capacity 1 | 28 |
| Hydraulic flow l/min | 21.6 |
| Hydraulic pressure bar | 160 |
| Transmission type | Hydrostatic |
